UL Type MV-105 Ampacities - Copper Conductors - Rated 5 kV to 35 kV
AMPACITIES
UL Type MV-105 Ampacities - Copper Conductors - Rated 5 kV to 35 kV
|
Ampacity |
Ampacity |
Ampacity |
Ampacity |
Ampacity |
|
 |
 |
 |
 |
 |
|
| 2023 NEC Article | Article 315.60(F) | Article 315.60(F) | Article 315.60(E) | Article 392.80(B)(2)(2) | Article 392.80(B)(2)(2) |
| 2023 NEC Table | Table 315.60(C)(19), One Circuit |
Table 315.60(C)(165, One Circuit |
Table 315.60(C)(7) | Table 315.60(C)(3) | Table 315.60(C)(3) |
| Cable Configuration | Figure 315.60(D)(3), Detail 7 |
Figure 315.60(D)(3), Detail 9 |
Touching | Single Layer, Spaced One Cable Diameter | Single Layer, Spaced One Cable Diameter |
| Installation Conditions | Earth Ambient = 20 deg C (68 F) Earth Thermal Resistivity = 0.90 deg C m / W Depth of Burial = 36 in |
Earth Ambient = 20 deg C (68 F) Earth Thermal Resistivity = 0.90 deg C m / W Depth of Burial = 36 in |
Ambient Air = 40 deg C (104 F) | Ambient Air = 40 deg C (104 F) | Ambient Air = 40 deg C (104 F) |
